EIKTO Professional lithium iron phosphate battery manufacturer.
Sales & Support:
 |
| Place of Origin: | Anhui China |
| Brand Name: | EIKTO |
| Certification: | CE/UL/UN38.3/SDS |
| Model Number: | YJT52145405-270Ah |
| Minimum Order Quantity: | 5 Pieces |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard safety industrial packaging |
| Delivery Time: | Less than 14 days within 10,000 pieces; more than 10,000 pieces requires negotiation. |
| Payment Terms: | EFT;Letter of Credit |
| Supply Ability: | +99999 |
| Product Name: | Lithium Iron Phosphate Battery | Product Model: | YJT52145405-270Ah |
|---|---|---|---|
| Rated Capacity: | 270Ah | Rated Voltage: | 3.2V |
| Battery Pack Size: | 52.8mm*145.5mm*405mm | Battery Pack Weight: | 5800g |
| High Light: | 3.2V270Ah Lithium Battery Cell,EIKTO Lithium Battery,Lithium Battery Cell LFP |
||
| NO. | Item | Specification | Remark |
| 1 | Dimension | 52.8mm*145.5mm*405mm | Fig.1, 50%SOC,200kgf |
| 2 | Rated Capacity | 270Ah | 25±2℃,1.0C |
| 3 | Nominal Voltage | 3.2V | / |
| 4 | AC Initial Impedance | ≤0.6mΩ |
25±2℃ AC 1KHz measured |
| 5 | Cell Weight | ≈5800g | / |
| 6 | Energy Density(Wh/kg) | 150 | / |
| 7 | Energy Density(Wh/L) | 279 | / |
| 8 | Max Charging Voltage | 3.6V | / |
| 9 | Maximum Continuous Charging Current | 1C | 25±5℃ |
| 10 | Discharge Cut-off Voltage | 2.5V | / |
| 11 | Max. Continuous Discharging Current | 1C | 25±5℃ |
| 12 | Standard cycle life | ≥4000times 80%Capacity retention | 1C/1C 25℃ |
1.terminal post heads on both sides of the battery.
2.CE/UL certified.
3.Winding process of anode and cathode electrode slice.
4.3000 charge & discharge cycles.
5.Lithium iron phosphate is the cathode material.
1.3.2V270Ah square lithium iron phosphate battery is designed with full electrode slice structure.
2.Terminal post on both sides, lower temperature rise and uniform temperature field.
3.More sufficient for current flow, making the battery safer.
4.Energy saving, environmental friendly, pollution-free, no mercury, cadmium and other heavy metal harmful substances.
5.Long cycle life, high safety and good stability.
1. Guaranteed delivery time.
2. Well-trained and disciplined packing team.
3. After-sale service:. Any questions or problems after receiving the product, please feel free to contact us. Problems would be solved for you immediately.
4. Sophisticated and professional logistic agent.
1. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia and many other countries.
2. Flexible and Untraceable payment terms.
3. Good after-sale service.
4. We offer high quality products at competitive price in quick delivery.
