EIKTO Professional lithium iron phosphate battery manufacturer.
Sales & Support:
 |
| Place of Origin: | Anhui China |
| Brand Name: | EIKTO |
| Certification: | CE/UL/UN38.3/SDS |
| Model Number: | EK-CP-0718 |
| Minimum Order Quantity: | One piece |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard safety industrial packaging |
| Delivery Time: | Within 30 days if order under 200 pieces; More than 200 pieces need to be negotiated. |
| Payment Terms: | EFT |
| Supply Ability: | +9999 |
| Rated Capacity: | 450Ah | Rated Voltage: | 80V |
|---|---|---|---|
| Size Of Battery Pack: | 1052mm*727mm*627mm | Weight Of Battery Pack: | 920kg |
| High Light: | 450ah Lawn Mower Lithium Battery,electric lawn mower lithium battery,80v Lawn Mower Lithium Battery |
||
| NO. | Item | Specification | Remark |
| 1 | Size | 1052mm*727mm*627mm | / |
| 2 | Combination mode | 3P25S | / |
| 3 | Rated capacity | 450Ah | 25±2℃,1.0C |
| 4 | Nominal voltage | 80V | / |
| 5 | High resistance | ≧50MΩ(DC500V) | 25±2℃ |
| 6 | Weight | ≈920kg | / |
| 7 | Total power of module | 36kwh | / |
| 8 | Maximum charging voltage | 90 | / |
| 9 | Maximum continuous charging current | 1C | 25±5℃ |
| 10 | Discharge cut-off voltage | 60 | / |
| 11 | Maximum continuous discharge current | 1C | 25±5℃ |
| 12 | Standard cycle life | ≥3000 times 80%Capacity retention | 1C/1C 25℃ |
1. This product is the standard module of EIKTO 10 core lithium iron phosphate battery, which is made of 150Ah lithium iron phosphate battery in series and parallel.
2. Laser welding is performed between batteries using iron connectors.
3. The iron material is used as the shell to stabilize the module, which has high structural strength.
4. The module can be equipped with a battery heating system to make the battery work normally in a low temperature environment.
5. The internal structure of the module is made of refractory materials, which greatly reduces the risk caused by heating.
6. The module has the advantages of light weight, strong stability, high safety and long cycle life.
1. The box is waterproof IP54, and the structure is firm
2. Reliable electrical performance to meet long-time work
3. Fast charging, safe and reliable;
4. It has remote monitoring and real-time viewing of battery information
The products are widely used in industrial vehicles, engineering vehicles and other fields.
